| Overview | Allen-Bradley 1756-HSC ControlLogix High Speed Counter, Series A |
|
|
|
| Mfr. Part Number: |
1756-HSC/A |
|
|
| Manufacturer: |
Rockwell Automation |
|
|
| Description: |
Allen-Bradley 1756-HSC ControlLogix High Speed Counter Module 2-Ch, 4-Out, Ser A |
|
|
| Full Description: |
Allen Bradley 1756-HSC ControlLogix High Speed Counter Module, 2 Channel, 4 Output (36 Pin), Series A |
|
|
| Status: |
Current Product |
| Inventory & Prices | Allen-Bradley 1756-HSC ControlLogix High Speed Counter, Series A |
|
|
|
|
| Condition: |
|
|
|
|
|
| Warranty: |
One Year Replacement Warranty |
|
|
|
|
| Availability: |
|
0 in stock |
|
0 available for pre-order |
|
|
|
|
|
| Shipping Date: |
|
|
|
|
|
| Retail Price: |
$990.00 |
|
|
|
|
| Your Price: |
$470.00 |
|
|
|
|
|
|
|
| Image |
 |
|
|
| Specs & Technical Data |
Allen-Bradley 1756-HSC ControlLogix High Speed Counter, Series A |
| Specifications: |
Allen Bradley 1756-HSC ControlLogix High Speed Counter Module, Mode of Operation: Counter - 1 MHz max., Rate Measurement - 500 kHz max., Encoder - 250 kHz max., Debounce filter - 70 Hz max; Number of Counters: 2; Inputs per Counter: 3 (A, B, Z for Gate/Reset); Counter Range: 0…16, 777, 214; Input voltage range: 5V operation: 4.5-5.5V DC, 12/24V operation: 10-31.2V DC; Number of Outputs: 4 (2 per common); Current draw at 5.1V: 300 mA; Current draw at 24V: 3 mA; Power dissipation, max: 5.6 W @ 60°C. |
|
|
| Miscellaneous: |
Allen Bradley 1756-HSC performs high-speed counting for industrial applications. The 1756-HSC High-speed Counter module counts incoming pulses from pulse generators, counters, limit switches, and other devices, and can either return a count to the controller or activate on-board outputs for a specific action depending on application. The 1756-HSC module provides four high-speed, output-switching, ON-OFF windows. The 1756HSC module uses pulses for counting and frequency. Required RTB: 1756-TBCH, 1756-TBS6H. |
|
