OverviewAllen-Bradley 1769-IF8 CompactLogix 8-Ch Analog Input Module, A
Mfr. Part Number:

1769-IF8/A

Manufacturer: Allen-Bradley / Rockwell Automation
Description: Allen-Bradley 1769-IF8 CompactLogix 8-Ch Analog Voltage/Current Input Module, A
Full Description: Allen-Bradley 1769-IF8 CompactLogix 8 Channel Analog Voltage/Current Input Module, Series A
UPC / GTIN: 10662468861134
Status: Current Product
Inventory & Prices
Condition:

NFO (New Factory Open)

Warranty: One Year Replacement Warranty
Availability:
0 in stock 0 available for pre-order
Shipping Date:
 -  -
Retail Price: $860.00
Your Price: $524.00
Quantity:


1769-IF8/A
Similar Parts Mfr Cond Description Retail Price Disc Qty
1769-IF8/A RA NSO Allen-Bradley 1769-IF8 CompactLogix 8-Ch Analog Voltage/Current Input Module, A $860.00 $546.00 -37% 1 buyit
1769-IF8/A RA NSS Allen-Bradley 1769-IF8 CompactLogix 8-Ch Analog Voltage/Current Input Module, A $860.00 $571.00 -34% 1 buyit
1769-IF8/A RA UPP Allen-Bradley 1769-IF8 CompactLogix 8-Ch Analog Voltage/Current Input Module, A $860.00 $250.00 -71% 13 buyit
Specs & Technical Data
Specifications: Allen-Bradley 1769-IF8 CompactLogix Analog Voltage/Current Input Module, Number of Inputs: 8 differential or single-ended; Resolution: 16 bits (unipolar), 15 bits + sign (bipolar); Signal Range: ±10V DC, 0-10V DC, 0-5V DC, 1-5V DC, 0-20 mA, 4-20 mA; Input Impedance: Voltage Terminal - 220K Ω, Current Terminal - 250 Ω; Overall Accuracy: Voltage ±0.2% full scale @ 25°C, Current ±0.35% full scale @ 25°C; Backplane Current @ 5.1V: 120 mA; Backplane Current @ 24V: 70 mA; Power Supply Distance Rating: 8 modules.
Miscellaneous: Allen-Bradley 1769-IF8 module converts and digitally stores analog data for retrieval by controllers, such as CompactLogix or MicroLogix 1500. The 1769-IF8 module allows connections from any combination of up to eight voltage or current analog sensors. All input channels can be wired as single-ended or differential inputs. The Allen-Bradley 1769-IF8 module supports the following data types: engineering units, scaled-for-PID, percent or raw/proportional data.
