Rockwell Automation > PLC & HMI > I/O Products > PLC-5 > 1771-IFE/C

OverviewAllen-Bradley 1771-IFE /C PLC-5 Analog Input Module, Series C
Mfr. Part Number:

1771-IFE/C

Manufacturer: Allen-Bradley / Rockwell Automation
Description: PLC-5 Analog Input Module, Inputs: 16 single ended or 8 differential, Series C
Full Description: Allen-Bradley 1771-IFE PLC-5 Analog Input Module, 12 Bit, Voltage or Current Inputs: 16-Inputs single ended or 8-Inputs differential, for use in 1771 I/O Chassis, Series C
UPC / GTIN: 10612598002211
Status: Current Product
Inventory & Prices
Condition:

NFS (New Factory Sealed)

Warranty: 30 Days Replacement Warranty
Availability:
0 in stock 1 available for pre-order
Shipping Date:
 - Ships within 3 working days
Retail Price: $5,660.00
Your Price: $2,152.00
Quantity:


1771-IFE/C
Similar Parts Mfr Cond Description Retail Price Disc Qty
1771-IFE/A RA UPP PLC-5 Analog Input Module, Inputs: 16 single ended or 8 differential, Series A $5,660.00 $112.00 -98% 27 buyit
1771-IFE/C RA NSO PLC-5 Analog Input Module, Inputs: 16 single ended or 8 differential, Series C $5,660.00 $1,256.00 -78% 2 buyit
1771-IFE/C RA NSS PLC-5 Analog Input Module, Inputs: 16 single ended or 8 differential, Series C $5,660.00 $1,842.00 -67% 1 buyit
1771-IFE/C RA UPP PLC-5 Analog Input Module, Inputs: 16 single ended or 8 differential, Series C $5,660.00 $141.00 -98% 1 buyit
1771-IFEK/C RA UPP Allen-Bradley 1771-IFEK Conformally Coated PLC-5 Analog Input Module, 12 Bit, C $4,280.00 $599.00 -86% 1 buyit
Specs & Technical Data
Specifications: Inputs: 16 single-ended, 8 differential low level; Module Location: 1771 I/O rack - 1 slot; Input Type: Voltage (default) or Current (change configuration plug to Current position). Input Voltage Ranges (nominal): +1 to +5V DC, 0 to +5V DC, -5 to +5V DC, -10 to +10V DC, 0 to +10V DC; Input Current Ranges (nominal): +4 to +20 mA, 0 to +20 mA, -20 to +20 mA; Resolution: 12-bit binary, 12 bits plus sign on bipolar ranges; Wiring Arm: Catalog Number 1771-WG.
Miscellaneous: 1771-IFE Series C difference from A and B: Has 6 bits of diagnostic information representing 6 possible faults; Returns input data above and below the range end points; Allows default scaling with both maximum and minimum scaling values as zero, no scaling error will be reported; Maximum block transfers lengths of 22 words for BTR and 39 words for BTW (due to autocalibration); is NOT compatible with 1771-AL local adapter.
