Rockwell Automation > PLC & HMI > Operator Interfaces > PanelView Standard > 2711-M3A19L1/A

OverviewAllen-Bradley 2711-M3A19L1 PanelView 300 Micro Mono DH-485 DC, A
Mfr. Part Number:

2711-M3A19L1/A

Manufacturer: Allen-Bradley / Rockwell Automation
Description: Allen-Bradley 2711-M3A19L1 PanelView 300 Micro Mono RS-232 (DH-485) 24V DC, A
Full Description: Allen-Bradley 2711-M3A19L1 PanelView 300 Micro Monochrome Terminal 3-inch, RS-232 (DH-485) Communication Port (8-pin mini-DIN), 24V DC Power, Series A
UPC / GTIN: 10611320385226
Status: Discontinued by manufacturer
Inventory & Prices
Condition:

UPP (Used in a PLCH Packaging)

Warranty: One Year Replacement Warranty
Availability:
1 in stock 0 available for pre-order
Shipping Date:
Same working day, by 6 pm ET  -
Retail Price: $2,618.00
Your Price: $615.00
Quantity:


2711-M3A19L1/A
Similar Parts Mfr Cond Description Retail Price Disc Qty
2711-M3A19L1/A RA NSO Allen-Bradley 2711-M3A19L1 PanelView 300 Micro Mono RS-232 (DH-485) 24V DC, A $2,618.00 $2,371.00 -9% 1 buyit
2711-M3A19L1/A RA NSS Allen-Bradley 2711-M3A19L1 PanelView 300 Micro Mono RS-232 (DH-485) 24V DC, A $2,618.00 $2,485.00 -5% 1 buyit
Specs & Technical Data
Specifications: Display Description: Monochrome transflective LCD with integral LED backlight; Display Area (WxH): 73 x 42 mm (2.87 x 1.67 in); Resolution: 128 x 64; Real-time Clock: Battery-back clock time stamps critical data; Application Software: PanelBuilder32 Software; Application Memory: 170 K Application Runtime; 240 K Flash (application objects + text + bitmaps); ATA Memory Card: N/A; Communication Ports: RS-232 (DH-485) Communication Port (8-Pin Mini DIN); Input Voltage, DC: 11-30V DC.
Miscellaneous: Broad range of terminal combinations to fit any operator interface application; Eight display combinations, from 3-inch to 10-inch, in color, grayscale or monochrome, each designed for minimal installation depth with maximum viewing angles; Keypad, touch screen, or keypad/touch screen combinations for convenient and flexible operator input; RS-232 printer port to print alarms, alarm lists, triggered messages, and triggered states of a multistate indicator; Field-replaceable backlights.
