OverviewSiemens 6SN1123-1AA00-0HA2 SIMODRIVE 611 Power Module 1-Axis 8 A
Mfr. Part Number:

6SN1123-1AA00-0HA2

Manufacturer: Siemens
Description: Siemens 6SN1123-1AA00-0HA2 SIMODRIVE 611 Power Module, 1-Axis, 8A, Int. Cooling
Full Description: Siemens 6SN1 123-1AA00-0HA2 SIMODRIVE 611 Power Module, 1-Axis, 8 A, Internal Cooling, Motor Motor Rated Current: 3A - Feed, 3A - Spindle
UPC / GTIN: 662643514100
Status: Current Product
Inventory & Prices
Condition:

NSO (New Surplus Open)

Warranty: One Year Replacement Warranty
Availability:
0 in stock 0 available for pre-order
Shipping Date:
 -  -
Retail Price: $951.48
Your Price: $1,291.00
Quantity:


6SN1123-1AA00-0HA2
Similar Parts Mfr Cond Description Retail Price Disc Qty
6SN1123-1AA00-0HA2 Siemens UPP Siemens 6SN1123-1AA00-0HA2 SIMODRIVE 611 Power Module, 1-Axis, 8A, Int. Cooling $951.48 $699.00 -27% 1 buyit
Specs & Technical Data
Specifications: Siemens 6SN1123-1AA00-0HA2 SIMODRIVE 611 Power Module, Number of Axis: 1; Heat Dissipation: Internal; Cooling Method: Self-Cooling; Degree of Protection: IP 20; Input Voltage: 600/625/680 VDC; Output Voltage: 0-430 VAC 3-Ph; Efficiency Eta: 0.98; Rated Current Output for 1FN/1FK/1FT Motors: 3A (Nominal), 6A (Peak); Rated Current Output for 1PH/1FE Motors and Asynchronous Motors: 3A (Nominal), 3A (S6-40%), 3A (Peak); DC Link Capacity: 150 µF; Dimensions, WxHxD: 50 x 480 x288 mm; Weight: 6.7 kg.
Miscellaneous: Together with the control module, the power module forms the drive module, for feed or main spindle applications. A wide range of 1–axis or 2–axis power modules is available. These modules are graded according to the current ratings and can be supplied with three different cooling techniques.
