OverviewAllen-Bradley 1756-ENBT ControlLogix EtherNet/IP Bridge, Ser. A
Mfr. Part Number:

1756-ENBT/A

Manufacturer: Allen-Bradley / Rockwell Automation
Description: ControlLogix EtherNet/IP Bridge Module 10/100 Mbps, 64 TCP/IP, Series A
Full Description: Allen-Bradley 1756-ENBT ControlLogix EtherNet/IP 10/100 Bridge Module - Twisted Pair, Supports a maximum of 64 TCP/IP connections and 128 Logix connections (I/O and information), 64 + 64 CIP Unconnected Messages (backplane + Ethernet); Max Number of Multicast Tags: 32; Unicast Available in RSLogix 5000 Software Version 16.03.00 or later; Socket Services; SNMP Support (password required), Duplicate IP Detection (starting in Revision 3.3); Packet Rate Capacity (packets/second): 500pps I/O, 900pps HMI/MSG; Series A
UPC / GTIN: 10612598269485
Status: Current Product
Inventory & Prices
Condition:

NFO (New Factory Open)

Warranty: One Year Replacement Warranty
Availability:
0 in stock 0 available for pre-order
Shipping Date:
 -  -
Retail Price: $2,560.00
Your Price: $775.00
Quantity:


1756-ENBT/A
Similar Parts Mfr Cond Description Retail Price Disc Qty
1756-ENBT/A RA NFS ControlLogix EtherNet/IP Bridge Module 10/100 Mbps, 64 TCP/IP, Series A $2,560.00 $935.00 -63% 3 buyit
1756-ENBT/A RA NSO ControlLogix EtherNet/IP Bridge Module 10/100 Mbps, 64 TCP/IP, Series A $2,560.00 $800.00 -69% 7 buyit
1756-ENBT/A RA NSS ControlLogix EtherNet/IP Bridge Module 10/100 Mbps, 64 TCP/IP, Series A $2,560.00 $920.00 -64% 7 buyit
1756-ENBT/A RA UPP ControlLogix EtherNet/IP Bridge Module 10/100 Mbps, 64 TCP/IP, Series A $2,560.00 $375.00 -85% 19 buyit
Specs & Technical Data
Specifications: Communication rate: 10/100 Mbps; Connections: Each module supports a maximum of 64 TCP/IP connections and 128 Logix connections (I/O and information); Current draw @ 5.1V DC: 700 mA; Current draw @ 24V DC: 3 mA; Power dissipation: 3.65 W; Ports: 1 Ethernet RJ45 Category 5; Ethernet cable: 802.3 compliant shielded or unshielded twisted pair; Isolation voltage: 30 V (continuous), Basic Insulation Type Tested at 707V DC for 60 s.
Miscellaneous: The 1756-ENBT is an enhanced version of the 1756-ENET module and works either as an interface for a ControlLogix controller to communicate with other devices over an EtherNet/IP network or as an adapter for 1756 I/O modules on an EtherNet/IP network. The 1756ENBT module communicates at a faster rate (10/100 Mbps full duplex vs. 10 Mbps half-duplex), includes more on-board memory, and is backward compatible replacing 1756-ENET modules without the need to modify current program. The module is web-enabled.
