Name: 1794-IRT8/B
Brand: Allen-Bradley
SKU: 1794IRT8B
Price: 999.00 USD
Availability: InStock

Rockwell Automation > PLC & HMI > I/O Products > Flex & Flex Ex > 1794-IRT8/B

Overview

Allen-Bradley 1794-IRT8 Flex Analog Input Module 8-In RTD/TC, B

Mfr. Part Number:	1794-IRT8/B

Manufacturer:	Allen-Bradley / Rockwell Automation

Description:	Allen-Bradley 1794-IRT8 Flex I/O Analog Input Module 8-In Thermocouple/RTD/Mv, B

Full Description:	Allen-Bradley 1794-IRT8 Flex I/O Analog Input Module, Non-Isolated, 8 Input Channels, Thermocouple/RTD/Mv/Strain Gauge, Series B

UPC / GTIN:	10612598180223

Status:	Current Product

Inventory & Prices

PLCH is Not Authorized Distributor of this product

Condition:

SOP (Surplus Open Pre-owned)

Warranty:

One Year PLCH Warranty.

Manufacturer's Warranty & Support DO NOT apply.

Availability:

1 in stock

Shipping Date:

Same working day, by 6 pm ET

Estimated Value:

Your Price:

$999.00

Quantity:


Disclaimer

PLC Hardware (PLCH) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens or any other Manufacturers. PLCH is NOT Authorized Dealer of this product. The product may be of older version, date codes or design than that available from authorized dealers. As PLCH is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. PLCH sells pre-owned SURPLUS and USED equipment ONLY and DOES NOT sell SOFTWARE or FIRMWARE licenses. Some hardware products may contain software and firmware and may not be legally operated without first obtaining a proper license from the manufacturer. PLCH makes no representation as to whether a product will or will not have software or firmware and, if it does, whether the software or firmware is the revision level that you need for your application. PLCH also makes no representations as to your ability or right to download or otherwise obtain software or firmware for the product from Original Manufacturer, its distributors, or any other source. PLCH also makes no representations as to your right to install any such software or firmware on the product. PLCH will not obtain or supply software or firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing software or firmware. Customer acknowledges and agrees that PLCH DOES NOT provide any software, firmware, operating system or right-to-use licenses with the products it sells. Customers understand and agree that proper software (firmware) licensing, maintenance and upgrades are subject to applicable manufacturer's Licensing Agreement or similar document.

Similar Parts	Mfr	Cond	Description	Est Val	Price	Stock	Qty

1794-IRT8/B	RA	SPP	Allen-Bradley 1794-IRT8 Flex I/O Analog Input Module 8-In Thermocouple/RTD/Mv, B		$2,224.00	3 days	2
1794-IRT8/B	RA	SSP	Allen-Bradley 1794-IRT8 Flex I/O Analog Input Module 8-In Thermocouple/RTD/mV, B		$1,163.00	in stock	2
1794-IRT8/B	RA	UPP	Allen-Bradley 1794-IRT8 Flex I/O Analog Input Module 8-In Thermocouple/RTD/Mv, B		$542.00	in stock	5
1794-IRT8XT/B	RA	UPP	Allen-Bradley 1794-IRT8XT FLEX I/O XT Analog Input 8-Ch Thermocouple/RTD/mV, B		$678.00	in stock	1

Specs & Technical Data

Specifications:	Allen-Bradley 1794-IRT8 Flex I/O Analog Input Module, Number of Inputs: 8 RTD, Thermocouple, Millivolt, Strain Gauge; Input Signal Range: -40…+100 mV DC for thermocouples, 0…325 mV DC for RTDs, 0…500 Ohm for resistance range; Input Resolution: 14 bits; External DC Supply Current, Nom.: 85 mA @ 24V DC; Power Dissipation, Max.: 3 W @ 31.2V DC; Common mode rejection: -80 db @ 5V peak-to-peak; Indicators: 1 green power status indicator, 8 red open input indicators; Terminal Base Unit: 1794-TB3G, 1794-TB3GS.

Miscellaneous:	Allen-Bradley 1794-IRT8 is a high-speed, high-accuracy temperature/mV measuring module that accepts thermocouple inputs, 2-, 3-, and 4-wire RTD inputs, and mV source inputs. The 1794-IRT8 also offers wire-off, over-range, and under-range detection. The 1794-IRT8 module accepts up to 8 thermocouple or RTD inputs. The cold-junction compensators (1794-CJC2) should be used in thermocouple mode. Two cold-junction compensators are shipped with any new 1794-IRT8 module.
