OverviewAllen-Bradley 1797-IE8 FLEX Ex I/O Analog Current 8-Input Module
Mfr. Part Number:

1797-IE8/A

Manufacturer: Allen-Bradley / Rockwell Automation
Description: Allen-Bradley 1797-IE8 FLEX Ex I/O Analog Current Input Module, 8 Points, Ser. A
Full Description: Allen-Bradley 1797-IE8 FLEX Ex I/O Analog Current Input Module, 0-20 mA, 8 Single-ended Inputs, 16 Bits, Series A
UPC / GTIN: 10612598172877
Status: Current Product
Inventory & Prices
Condition:

NSO (New Surplus Open)

Warranty: One Year Replacement Warranty
Availability:
0 in stock 0 available for pre-order
Shipping Date:
 -  -
Retail Price: $2,750.00
Your Price: $1,353.00
Quantity:


1797-IE8/A
Specs & Technical Data
Specifications: Allen-Bradley 1797-IE8 FLEX Ex I/O Analog Current Input Module, Number of Inputs: 8 single-ended; Input Signal Range: 0-20 mA; Resolution: 16 bits; Accuracy: 0.1%; Data Format: Configurable; Update Time, Module from Adapter: 200-1600 microsec; Step Response to 99% of Full Scale: 4 ms; Indicators: 8 red fault indicators, 1 green power; Keyswitch Position: 3; Power Dissipation, Max.: 5.2 W; Dimensions: 46mm x 94mm x 75mm (1.8in x 3.7in x 2.95in); Weight: 200g;Terminal Base Unit: 1797-TB3, 1797-TB3S.
Miscellaneous: Allen-Bradley 1797-IE8 module accepts up to 8 analog inputs. The inputs are non-isolated and will accept current in either of the following two ranges: 4-20mA or 0-20mA. The default input range is 0-20mA. The inputs have both fixed hardware filters and selectable firmware digital filters. All features of the 1797-IE8 analog input module are independently configurable in two four-channel groups (channel 0-3 & channel 4-7). The Intrinsically Safe (IS) +/-V power is required for 1797-IE8 module.
