OverviewAllen-Bradley 1769-IQ16F High Speed Input Module 16-Ch 24V DC, A
Mfr. Part Number:


Manufacturer: Allen-Bradley / Rockwell Automation
Description: Allen-Bradley 1769-IQ16F CompactLogix 24V DC High-Speed Input Module 16-Point, A
Full Description: Allen-Bradley 1769-IQ16F Compact I/O 24V DC Sink/Source High-Speed Digital Input Module, 16 Inputs (8 points/group), Series A
UPC / GTIN: 10611320915676
Status: Current Product
Inventory & Prices

NSO (New Surplus Open)

Warranty: One Year Replacement Warranty
0 in stock 0 available for pre-order
Shipping Date:
 -  -
Retail Price: $317.00
Your Price: $251.00
Similar Parts Mfr Cond Description Retail Price Disc Qty
1769-IQ16F/A RA UPP Allen-Bradley 1769-IQ16F CompactLogix 24V DC High-Speed Input Module 16-Point, A $317.00 $129.00 -59% 6 buyit
Specs & Technical Data
Specifications: Allen-Bradley 1769-IQ16F Compact I/O High-Speed Digital DC Input Module, Number of Inputs: 16 Inputs (8 points/group); Voltage Category: 24V DC (Sink/Source); Operating Voltage Range: 10...30V DC @ 30 °C (86 °F), 10...26.4V DC @ 60 °C (140 °F); Hardware Delay: OFF to ON - 100 microsec (typical), 300 microsec (max), ON to OFF - 250 microsec (typical), 1 ms (max); Current, On-State Input, Min: 2.0 mA; Current, Off-State Input, Max: 1.5 mA; Backplane Current @ 5V: 110mA (0.55 W); PS Distance Rating: 8 modules.
Miscellaneous: Allen-Bradley 1769-IQ16F input module responds to an input signal in the following manner: an input LED turns on or off indicating the status of the corresponding input device. The 1769-IQ16F input modules use input filtering. Input filtering limits the effect of voltage transients caused by contact bounce and/or electrical noise. Each 1769-IQ16F module includes a built-in removable terminal block with finger-safe cover for connections to I/O sensors and actuators.
