Name: 1794-IF4I/A
Brand: Allen-Bradley
SKU: 1794IF4IA
Price: 581.00 USD
Availability: InStock

Rockwell Automation > PLC & HMI > I/O Products > Flex & Flex Ex > 1794-IF4I/A

Overview

Allen-Bradley 1794-IF4I FLEX I/O Analog Isolated Input Module, A

Mfr. Part Number:	1794-IF4I/A

Manufacturer:	Allen-Bradley / Rockwell Automation

Description:	Allen-Bradley 1794-IF4I FLEX I/O Analog Input Module 4 Isolated Inputs, Series A

Full Description:	Allen-Bradley 1794-IF4I FLEX I/O Analog Input Module, 4 Isolated Inputs, 16 Bit, Series A

UPC / GTIN:	10612598171573

Status:	Current Product

Inventory & Prices

PLCH is Not Authorized Distributor of this product

Condition:

SOP (Surplus Open Pre-owned)

Warranty:

One Year PLCH Warranty.

Manufacturer's Warranty & Support DO NOT apply.

Availability:

1 in stock

Shipping Date:

Same working day, by 6 pm ET

Estimated Value:

Your Price:

$581.00

Quantity:


Disclaimer

PLC Hardware (PLCH) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens or any other Manufacturers. PLCH is NOT Authorized Dealer of this product. The product may be of older version, date codes or design than that available from authorized dealers. As PLCH is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. PLCH sells pre-owned SURPLUS and USED equipment ONLY and DOES NOT sell SOFTWARE or FIRMWARE licenses. Some hardware products may contain software and firmware and may not be legally operated without first obtaining a proper license from the manufacturer. PLCH makes no representation as to whether a product will or will not have software or firmware and, if it does, whether the software or firmware is the revision level that you need for your application. PLCH also makes no representations as to your ability or right to download or otherwise obtain software or firmware for the product from Original Manufacturer, its distributors, or any other source. PLCH also makes no representations as to your right to install any such software or firmware on the product. PLCH will not obtain or supply software or firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing software or firmware. Customer acknowledges and agrees that PLCH DOES NOT provide any software, firmware, operating system or right-to-use licenses with the products it sells. Customers understand and agree that proper software (firmware) licensing, maintenance and upgrades are subject to applicable manufacturer's Licensing Agreement or similar document.

Similar Parts	Mfr	Cond	Description	Est Val	Price	Stock	Qty

1794-IF4I/A	RA	UPP	Allen-Bradley 1794-IF4I FLEX I/O Analog Input Module 4 Isolated Inputs, Series A		$332.00	3 days	7
1794-IF4IXT/A	RA	SSP	Allen-Bradley 1794-IF4IXT Flex I/O-XT Analog Input Module, 4 Isolated Inputs, A		$445.00	in stock	5
1794-IF4IXT/A	RA	UPP	Allen-Bradley 1794-IF4IXT Flex I/O-XT Analog Input Module, 4 Isolated Inputs, A		$547.00	3 days	2

Specs & Technical Data

Specifications:	Allen-Bradley 1794-IF4I FLEX I/O Analog Input Module, Number of Inputs: 4 Isolated Inputs; Signal Range: 4-20mA, 0-20mA, ±20mA, ±10V, 0-10V, ±5V, 0-5V; Input Conversion Rate: 2.5/5.0/7.5ms on all channels; Input Resolution: 16 bits - Unipolar, 15 bits + sign - Bipolar, 0.320μA/Cnt - Unipolar, 0.640μA/Cnt - Bipolar, 0.156μV/Cnt - Unipolar, 0.313μV/Cnt – Bipolar; External DC Supply Current, Nom: 80mA @ 24V DC; Power Dissipation, Max: 2W @ 31.2V DC; Terminal Base: 1794-TB3, -TB2, -TB3S, -TB3T, -TB3TS, -TBN.

Miscellaneous:	Allen-Bradley 1794-IF4I FLEX I/O Input Modules have selectable input filtering built into the A/D converter. The filter attenuates the input signal beginning at the specified frequency and can be select from 150, 300, 600, and 1200Hz with low pass filters of none, 100ms, 500ms or 1000ms. The 1794-IF4I is used with 2-, 3-, and 4-wire Input Sensor field devices. The 1794-TB3 is recommended Terminal Base for 1794-IF4I module.
